How do you read a stabilus number?

How do you read a stabilus number?

The number is listed in the red square and consists of six digits or 4 digits and 2 letters. The number to the right is the pressure (here: 900N).

Where is the part number on a stabilus lift O Mat?

On the body of the Stabilus gas strut you will find the part number (product code) in the area marked in BLUE on the image below. The Lift o mat part number will usually consist of 6 numbers, letters or a combination of both depending on the use, followed by the Newton Force.

What is stabilus lift O Mat?

The LIFT-O-MAT gas spring is a hydropneumatic adjustment element consisting of a pressure tube, piston rod with piston, as well as a suitable end fitting. It is filled with nitrogen, which, under constant pressure, acts on piston cross sections of different sizes, creating a force in the extension direction.

How do you unlock stabilus lift mat?

To unlock, the support tube is swivelled back into the central position. The lock of a gas spring with the lock on the inside is comparable with the mechanics of a ball point pen. A light push on the piston rod in the extended position locks it; a quick movement in the extension direction releases the lock.

How are gas struts measured?

How To Measure Gas Struts

1. Measure the Gas Strut when it is fully extended from the Centre of the End Fittings.
2. Measure the Diameter of both the Barrel and the Rod.
3. Measure the exposed Rod length from the Barrel to the centre of the End Fitting.

How do you adjust gas struts?

Using the Allen key provided undo the grub screw until gas can be heard escaping. Then re-tighten the grub screw. Only release the gas in one second bursts to avoid releasing too much gas. Repeat the process until the gas strut is behaving as desired.

How do you release a lift O Mat?

To unlock, the support tube is swiveled back into the central position. The lock of a gas spring with the lock on the inside is comparable with the mecha- nics of a ball point pen. A light push on the piston rod in the extended position locks it; a quick movement in the extension direc- tion releases the lock.

How do you read gas struts?

How to Measure

1. Step 1 – Extended Length. Measure the gas strut from middle of end fitting to the middle of the end fitting when gas strut is fully extended.
2. Step 2 – Diameter. Measure across the Rod/Shaft.
3. Step 3 – Newton Meters or Force.
4. Step 4 – End Fittings.
5. Step 5 – Order your Gas Strut.
